TN22-1500H Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Thyristors - SCRs Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- Description: SCR 400V 2A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
TN22-1500H Specifications:
- MfrPart.: TN22-1500H
- Mfr: STMicroelectronics
- Description: SCR 400V 2A IPAK
- Product Category: Discrete Semiconductor Products~Thyristors - SCRs
- Package: Tube
- Series: -
- PartStatus: Active
- Voltage-OffState: 400 V
- Voltage-GateTrigger(Vgt)(Max): 3 V
- Current-GateTrigger(Igt)(Max): 1.5 mA
- Voltage-OnState(Vtm)(Max): 3.1 V
- Current-OnState(It(AV))(Max): 1.8 A
- Current-OnState(It(RMS))(Max): 2 A
- Current-Hold(Ih)(Max): 175 mA
- Current-OffState(Max): 100 µA
- Current-NonRepSurge5060Hz(Itsm): 20A, 22A
- SCRType: Standard Recovery
- OperatingTemperature: -40°C ~ 110°C
- MountingType: Through Hole
- Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- TN22-1500H STMicroelectronics, SCR 400V 2A IPAK, Discrete Semiconductor Products~Thyristors - SCRs
TN22-1500H, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
