STW80NF06 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: MOSFET N-CH 60V 80A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW80NF06 Specifications:
- MfrPart.: STW80NF06
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 60V 80A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 8mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 150 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3850 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 300W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- STW80NF06 STMicroelectronics, MOSFET N-CH 60V 80A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW80NF06, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
