STW20NK70Z Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-247-3
- Description: MOSFET N-CH 700V 20A TO247-3
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STW20NK70Z Specifications:
- MfrPart.: STW20NK70Z
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 700V 20A TO247-3
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: SuperMESH™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 700 V
- Current-ContinuousDrain(Id)@25°C: 20A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 285mOhm @ 10A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 150µA
- GateCharge(Qg)(Max)@Vgs: 185 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 6000 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 350W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-247-3
- STW20NK70Z STMicroelectronics, MOSFET N-CH 700V 20A TO247-3, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STW20NK70Z, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
