STP16N60M2 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220AB
- Description: MOSFET N-CH 600V 12A TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STP16N60M2 Specifications:
- MfrPart.: STP16N60M2
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 12A TO220
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ M2
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 320mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 19 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 700 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 110W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220AB
- STP16N60M2 STMicroelectronics, MOSFET N-CH 600V 12A TO220, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STP16N60M2, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
