STN3NF06L Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: SOT-223
- Description: MOSFET N-CH 60V 4A SOT223
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STN3NF06L Specifications:
- MfrPart.: STN3NF06L
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 60V 4A SOT223
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 100mOhm @ 1.5A, 10V
- Vgs(th)(Max)@Id: 2.8V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 9 nC @ 5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 340 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 3.3W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: SOT-223
- STN3NF06L STMicroelectronics, MOSFET N-CH 60V 4A SOT223, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STN3NF06L, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
