STL6NM60N Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: PowerFLAT™ (5x5)
- Description: MOSFET N-CH 600V 5.75A POWERFLAT
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STL6NM60N Specifications:
- MfrPart.: STL6NM60N
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 5.75A POWERFLAT
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 5.75A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 920mOhm @ 2.3A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 13 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 420 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 70W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: PowerFLAT™ (5x5)
- STL6NM60N STMicroelectronics, MOSFET N-CH 600V 5.75A POWERFLAT, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STL6NM60N, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
