STGWT30H65FB Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3, SC-65-3
- Description: IGBT 650V 30A 260W TO3PL
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWT30H65FB Specifications:
- MfrPart.: STGWT30H65FB
- Mfr: STMicroelectronics
- Description: IGBT 650V 30A 260W TO3PL
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 30A
- Power-Max: 260 W
- SwitchingEnergy: 151µJ (on), 293µJ (off)
- InputType: Standard
- GateCharge: 149 nC
- Td(on/off)@25°C: 37ns/146ns
- TestCondition: 400V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3, SC-65-3
- STGWT30H65FB STMicroelectronics, IGBT 650V 30A 260W TO3PL, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGWT30H65FB, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
