STGWA35HF60WDI Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 70A 260W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGWA35HF60WDI Specifications:
- MfrPart.: STGWA35HF60WDI
- Mfr: STMicroelectronics
- Description: IGBT 600V 70A 260W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 70 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 20A
- Power-Max: 260 W
- SwitchingEnergy: 185µJ (off)
- InputType: Standard
- GateCharge: 140 nC
- Td(on/off)@25°C: 30ns/175ns
- TestCondition: 390V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 85 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGWA35HF60WDI STMicroelectronics, IGBT 600V 70A 260W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
