STGW40NC60KD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-247-3
- Description: IGBT 600V 70A 250W TO247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGW40NC60KD Specifications:
- MfrPart.: STGW40NC60KD
- Mfr: STMicroelectronics
- Description: IGBT 600V 70A 250W TO247
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 70 A
- Current-CollectorPulsed(Icm): 220 A
- Vce(on)(Max)@VgeIc: 2.7V @ 15V, 30A
- Power-Max: 250 W
- SwitchingEnergy: 595µJ (on), 716µJ (off)
- InputType: Standard
- GateCharge: 135 nC
- Td(on/off)@25°C: 46ns/164ns
- TestCondition: 480V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 45 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-247-3
- STGW40NC60KD STMicroelectronics, IGBT 600V 70A 250W TO247, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGW40NC60KD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
