STGFW30NC60V Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3 Full Pack
- Description: IGBT 600V 36A 80W TO3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGFW30NC60V Specifications:
- MfrPart.: STGFW30NC60V
- Mfr: STMicroelectronics
- Description: IGBT 600V 36A 80W TO3PF
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 36 A
- Current-CollectorPulsed(Icm): 100 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 20A
- Power-Max: 80 W
- SwitchingEnergy: 220µJ (on), 330µJ (off)
- InputType: Standard
- GateCharge: 100 nC
- Td(on/off)@25°C: 31ns/100ns
- TestCondition: 390V, 20A, 3.3Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3 Full Pack
- STGFW30NC60V STMicroelectronics, IGBT 600V 36A 80W TO3PF, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGFW30NC60V, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
