STGF7NB60SL Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 15A 25W TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGF7NB60SL Specifications:
- MfrPart.: STGF7NB60SL
- Mfr: STMicroelectronics
- Description: IGBT 600V 15A 25W TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 15 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 1.6V @ 4.5V, 7A
- Power-Max: 25 W
- SwitchingEnergy: 4.1mJ (off)
- InputType: Standard
- GateCharge: 16 nC
- Td(on/off)@25°C: 1.1µs/5.2µs
- TestCondition: 480V, 7A, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- STGF7NB60SL STMicroelectronics, IGBT 600V 15A 25W TO220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGF7NB60SL, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
