STGD7NB120ST4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 1200V 10A 55W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD7NB120ST4 Specifications:
- MfrPart.: STGD7NB120ST4
- Mfr: STMicroelectronics
- Description: IGBT 1200V 10A 55W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR)
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 7A
- Power-Max: 55 W
- SwitchingEnergy: 3.2µJ (on), 15mJ (off)
- InputType: Standard
- GateCharge: 29 nC
- Td(on/off)@25°C: 570ns/-
- TestCondition: 960V, 7A, 1kOhm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- STGD7NB120ST4 STMicroelectronics, IGBT 1200V 10A 55W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGD7NB120ST4, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
