STGB40H65FB Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT BIPO 650V 40A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB40H65FB Specifications:
- MfrPart.: STGB40H65FB
- Mfr: STMicroelectronics
- Description: IGBT BIPO 650V 40A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: HB
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 80 A
- Current-CollectorPulsed(Icm): 160 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 40A
- Power-Max: 283 W
- SwitchingEnergy: 498µJ (on), 363µJ (off)
- InputType: Standard
- GateCharge: 210 nC
- Td(on/off)@25°C: 40ns/142ns
- TestCondition: 400V, 40A, 5Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB40H65FB STMicroelectronics, IGBT BIPO 650V 40A D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGB40H65FB, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
