STGB35N35LZT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 345V 40A 176W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB35N35LZT4 Specifications:
- MfrPart.: STGB35N35LZT4
- Mfr: STMicroelectronics
- Description: IGBT 345V 40A 176W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 345 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 1.7V @ 4.5V, 15A
- Power-Max: 176 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 49 nC
- Td(on/off)@25°C: 1.1µs/26.5µs
- TestCondition: 300V, 15A, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB35N35LZT4 STMicroelectronics, IGBT 345V 40A 176W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
