STD11N60M2-EP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 600V 7.5A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD11N60M2-EP Specifications:
- MfrPart.: STD11N60M2-EP
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 600V 7.5A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ M2-EP
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 600 V
- Current-ContinuousDrain(Id)@25°C: 7.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 595mOhm @ 3.75A, 10V
- Vgs(th)(Max)@Id: 4.75V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 12.4 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 390 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 85W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD11N60M2-EP STMicroelectronics, MOSFET N-CH 600V 7.5A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
