STD10NF30 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CHANNEL 300V 10A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD10NF30 Specifications:
- MfrPart.: STD10NF30
- Mfr: STMicroelectronics
- Description: MOSFET N-CHANNEL 300V 10A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, MESH OVERLAY™, MESH OVERLAY™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 300 V
- Current-ContinuousDrain(Id)@25°C: 10A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 330mOhm @ 5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 23 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 780 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 103W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD10NF30 STMicroelectronics, MOSFET N-CHANNEL 300V 10A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD10NF30, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
