ST3DV520QTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 56-WFQFN Exposed Pad
- Description: IC MUX/DEMUX QUAD 2X1 56QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
ST3DV520QTR Specifications:
- MfrPart.: ST3DV520QTR
- Mfr: STMicroelectronics
- Description: IC MUX/DEMUX QUAD 2X1 56QFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 4
- On-StateResistance(Max): 7.5Ohm
- Channel-to-ChannelMatching(ΔRon): 500mOhm
- Voltage-SupplySingle(V+): 3V ~ 3.6V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 9ns, 8.5ns
- -3dbBandwidth: 450MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 6pF
- Current-Leakage(IS(off))(Max): 5µA
- Crosstalk: -45dB @ 250MHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 56-WFQFN Exposed Pad
- ST3DV520QTR STMicroelectronics, IC MUX/DEMUX QUAD 2X1 56QFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
ST3DV520QTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
