SCTH100N65G2-7AG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: H2PAK-7
- Description: SICFET N-CH 650V 95A H2PAK-7
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SCTH100N65G2-7AG Specifications:
- MfrPart.: SCTH100N65G2-7AG
- Mfr: STMicroelectronics
- Description: SICFET N-CH 650V 95A H2PAK-7
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 650 V
- Current-ContinuousDrain(Id)@25°C: 95A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 18V
- RdsOn(Max)@IdVgs: 26mOhm @ 50A, 18V
- Vgs(th)(Max)@Id: 5V @ 5mA
- GateCharge(Qg)(Max)@Vgs: 162 nC @ 18 V
- Vgs(Max): +22V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 3315 pF @ 520 V
- FETFeature: -
- PowerDissipation(Max): 360W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: H2PAK-7
- SCTH100N65G2-7AG STMicroelectronics, SICFET N-CH 650V 95A H2PAK-7, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SCTH100N65G2-7AG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
