M74HC4066TTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 14-TSSOP (0.173, 4.40mm Width)
- Description: IC SWITCH QUAD 2X1 14TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
M74HC4066TTR Specifications:
- MfrPart.: M74HC4066TTR
- Mfr: STMicroelectronics
- Description: IC SWITCH QUAD 2X1 14TSSOP
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPST - NO
- Multiplexer/DemultiplexerCircuit: 1:1
- NumberofCircuits: 4
- On-StateResistance(Max): 80Ohm
- Channel-to-ChannelMatching(ΔRon): 5Ohm
- Voltage-SupplySingle(V+): 2V ~ 12V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 12ns, 18ns
- -3dbBandwidth: 200MHz
- ChargeInjection: -
- ChannelCapacitance(CS(off)CD(off)): 0.5pF, 5pF
- Current-Leakage(IS(off))(Max): 100nA
- Crosstalk: -60dB @ 1MHz
- OperatingTemperature: -55°C ~ 125°C (TA)
- MountingType: Surface Mount
- Package/Case: 14-TSSOP (0.173, 4.40mm Width)
- M74HC4066TTR STMicroelectronics, IC SWITCH QUAD 2X1 14TSSOP, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
M74HC4066TTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
