L7820CV Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-220-3
- Description: IC REG LINEAR 20V 1.5A TO220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
L7820CV Specifications:
- MfrPart.: L7820CV
- Mfr: STMicroelectronics
- Description: IC REG LINEAR 20V 1.5A TO220AB
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
- Package: Tube
- Series: -
- PartStatus: Obsolete
- OutputConfiguration: Positive
- OutputType: Fixed
- NumberofRegulators: 1
- Voltage-Input(Max): 40V
- Voltage-Output(Min/Fixed): 20V
- Voltage-Output(Max): -
- VoltageDropout(Max): 2V @ 1A (Typ)
- Current-Output: 1.5A
- Current-Quiescent(Iq): 8 mA
- Current-Supply(Max): -
- PSRR: 52dB (120Hz)
- ControlFeatures: -
- ProtectionFeatures: Over Temperature, Short Circuit
- OperatingTemperature: 0°C ~ 125°C
- MountingType: Through Hole
- Package/Case: TO-220-3
- L7820CV STMicroelectronics, IC REG LINEAR 20V 1.5A TO220AB, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
L7820CV, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
